The CCAC1425 is a high-resolution (480 TVL) colour camera with built-in auto focus zoom lens with maximum 242x zoom. The camera is designed for indoor use under variable lighting conditions.

All the camera settings such as white balance, exposure settings, setting of back-light compensation (BLC), line-lock synchronisation or digital noise reduction are done via the OSD menu. Each camera can have an individual camera text assigned to it. It is possible to specify via the display menu which text and which detailed information for the setting of the camera is to be displayed in the video image.

The camera offers the option to be switched from colour to monochrome operation by means of an external switch. The status of the camera can be superimposed in the video image. A small live image can be superimposed by means of the PIP function. In this way, it is therefore possible to freeze an image sequence with the freeze function while the live image continues to be displayed in the PIP window.

The camera can also be controlled and parameterised with the standard Siemens SCU protocol and the Bewator-Molynx protocol via the built-in RS485 interface. In addition, the camera can also be operated with voltage-controlled inputs. The zoom and aperture functions and switching of the operating mode from colour to monochrome can be set here.

The CCAC1415 is a high resolution (480 TVL) colour camera with built-in auto focus zoom lens with maximum 242x zoom. The camera is designed for outdoor use under variable lighting conditions. It is built into a compact and attractively styled weatherproof housing with sunshield incorporated.

All the camera settings such as white balance, exposure settings, setting of back-light compensation (BLC), line-lock synchronisation or digital noise reduction are done via the OSD menu. Each camera can have an individual camera text assigned to it. It is possible to specify via the display menu which text and which detailed information for the setting of the camera is to be displayed in the video image.

The camera offers the option to be switched from colour to monochrome operation by means of an external switch. The status of the camera can be superimposed in the video image.

The CCAS1425-LPO / MPO is a high resolution (480 / 530 TVL) day-night camera with built-in auto focus zoom lens with maximum 242x zoom. The camera is designed for outdoor use under variable lighting conditions. It is built into a compact and attractively styled weatherproof housing with sunshade incorporated. As a result of the day-night function, the camera offers optimum picture quality both under varying daylight conditions and also when used at night with IR light.

All the camera settings such as white balance, exposure settings, setting of back-light compensation (BLC), line-lock synchronisation or digital noise reduction are done via the OSD menu. Each camera can have an individual camera text assigned to it. It is possible to specify via the display menu which text and which detailed information for the setting of the camera is to be displayed in the video image.

The CVAC1415-LPO is a high resolution (480 TVL) colour camera with built-in auto focus zoom lens with maximum 242x zoom. The camera is designed for outdoor use under variable lighting conditions and is built into a compact and attractively styled vandal-resistant housing.

All the camera settings such as white balance, exposure settings, setting of back-light compensation (BLC), line-lock synchronisation or digital noise reduction are done via the OSD menu. Each camera can have an individual camera text assigned to it. It is possible to specify via the display menu which text and which detailed information for the setting of the camera is to be displayed in the video image.

The camera offers the option to be switched from colour to B&W operation by means of an external switch and the status of the camera can be super-imposed in the video image.

A small live image can also be super-imposed by means of the Picture in Picture (PIP) function. In this way it is thus possible to freeze an image sequence with the freeze function while the live image continues to be displayed in the IP window.

The CVAS1415-LPO is a high resolution (480 / 530 TVL) day-night camera with built-in auto focus zoom lens with maximum 242x zoom. The camera is designed for outdoor use under variable lighting conditions and is built into a compact and attractively styled vandal-resistant housing.

All the camera settings such as white balance, exposure settings, setting of back-light compensation (BLC), line-lock synchronisation or digital noise reduction are done via the OSD menu. Each camera can have an individual camera text assigned to it. It is possible to specify via the display menu which text and which detailed information for the setting of the camera is to be displayed in the video image.

The camera offers the option to be switched from colour to B&W operation by means of an external switch and the status of the camera can be super-imposed in the video image.

A small live image can also be super-imposed by means of the Picture in Picture (PIP) function. In this way it is thus possible to freeze an image sequence with the freeze function while the live image continues to be displayed in the IP window.
